Package contains: 4 pistons with rings, pins Cyl.Bore: 76.00mm is STD Compression Height: 30.2mm Length: 60.7mm Recess Depth: +0.5mm Bolt d.: 19.0mm Bolt Length: 58.0mm Info: Circlip not required Piston rings: 1.20x1.50x3.00mm

Package contains: 3 pistons with rings, pins Cyl.Bore: 71.90mm is STD Compression Height: 27.3mm Length: 50.9mm Recess Depth: +5.6/-3.2mm Recess Diameter: 42.8mm Bolt d.: 20.0mm Bolt Length: 47.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.00x1.20x2.00mm

Package contains: 3 pistons with rings, pins Cyl.Bore: 84.00mm is STD Compression Height: 29.5mm Length: 49.3mm Recess Depth: +1.8/-1.95mm Bolt d.: 21.0mm Bolt Length: 54.0mm Info: Alfin, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 79.00mm is STD Compression Height: 28.6mm Length: 54.0mm Recess Depth: +6.4/-5.2mm Bolt d.: 21.0mm Bolt Length: 46.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.045mm when measured at 10.0mm above the skirt Piston rings:...

Package contains: 4 pistons with rings, pins Cyl.Bore: 79.00mm is STD Compression Height: 28.6mm Length: 54.0mm Recess Depth: +6.4/-5.2mm Bolt d.: 21.0mm Bolt Length: 46.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.045mm when measured at 10.0mm above the skirt Piston rings:...

Package contains: 4 pistons with rings, pins Cyl.Bore: 79.00mm is STD Compression Height: 28.7mm Length: 53.9mm Recess Depth: +6.1/-3.4mm Bolt d.: 21.0mm Bolt Length: 46.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 86.00mm is STD Compression Height: 43.4mm Length: 69.8mm Recess Depth: -6.0/-15.8mm Bolt d.: 30.0mm Bolt Length: 66.8mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 2.00x2.00x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 86.00mm is STD Compression Height: 43.4mm Length: 69.8mm Recess Depth: -6.0/-15.8mm Bolt d.: 30.0mm Bolt Length: 66.8mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 2.00x2.00x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 86.00mm is STD Compression Height: 48.4mm Length: 74.8mm Recess Depth: -6.4/-16.2mm Recess Diameter: 49.0mm Bolt d.: 30.0mm Bolt Length: 67.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 2.00x2.00x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm
