Cyl.Bore: 75.00mm is STD Compression Height: 30.8mm Length: 48.3mm Recess Depth: -2.74mm Bolt d.: 19.0mm Bolt Length: 51.0mm Info: 1st ring groove anodized, skirt MOS2 treated, fits tapered con. rod/td> Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 77.00mm is STD Compression Height: 27.0mm Length: 46.0mm Recess Depth: -2.6mm Bolt d.: 19.0mm Bolt Length: 40.5mm Info: 1st ring groove anodized, skirt MOS2 treated, fits tapered con. rod/td> Piston rings: 1.20x1.20x2.00mm

Enables swift and accurate checking of the bearing clearance on cross-divided plain bearings. It is especially well suited for checking the clearance of crankshaft main, con-rod and camshaft bearings on the engines of passenger cars and commercial vehicles. 'KS Plastic Gauge' is a thin, calibrated plastic strip which is inserted into the oil-free bearing position to measure the bearing...

Conrod design: trapezoidal connecting rod Large connecting rod eye bore diameter: 51.6mm Small connecting rod eye diameter: 30.0mm Width big end: 22.0mm Width small end: 22.0mm Type of connecting rod separation: cracked Length: 149.0mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 52.980 / 53.000mm Housing bore: 56.000 / 56.019mm Wall thickness: 1.487mm Bearing width: 24.45mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 52.980 / 53.000mm Housing bore: 56.000 / 56.019mm Wall thickness: 1.487mm Bearing width: 24.45mm

Position: Crankshaft Quantity: 1 pairs Shaft diameter: 69.940 / 69.960mm Housing bore: 74.500 / 74.520mm Wall thickness: 2.25mm Bearing width: 19.60mm Position: Crankshaft Quantity: 2 pair Shaft diameter: 64.940 / 64.960mm Housing bore: 69.500 / 69.520mm Wall thickness: 2.25mm Bearing width: 23.30mm Position: Crankshaft Quantity: 2 pair Shaft...

Position: Crankshaft Quantity: 1 pairs Shaft diameter: 69.940 / 69.960mm Housing bore: 74.500 / 74.520mm Wall thickness: 2.25mm Bearing width: 19.60mm Position: Crankshaft Quantity: 2 pair Shaft diameter: 64.940 / 64.960mm Housing bore: 69.500 / 69.520mm Wall thickness: 2.25mm Bearing width: 23.30mm Position: Crankshaft Quantity: 2 pair Shaft...

Position: Crankshaft Quantity: 5 pairs Shaft diameter: 47.963 / 47.978mm Housing bore: 53.000 / 53.019mm Wall thickness: 2.51mm Bearing width: 15.50mm

Position: Connecting rod Quantity: 6 pairs Shaft diameter: 59.958 / 59.978mm Housing bore: 63.600 / 63.619mm Wall thickness: 1.801mm Bearing width: 16.40mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 49.982 / 50.000mm Housing bore: 53.017 / 53.030mm Wall thickness: 1.503mm Bearing width: 21.20mm

Position: Crankshaft Quantity: 5 pairs Shaft diameter: 54.979 / 55.000mm Housing bore: 59.014 / 59.032mm Wall thickness: 2.003mm Bearing width: 21.50mm
