Bearing structure: Tri-Metal; Number in pack: 26

Package contains: 4 pistons with rings, pins Cyl.Bore: 77.00mm is STD Compression Height: 28.5mm Length: 51.2mm Recess Depth: +2.7/-3.5mm Bolt d.: 20.0mm Bolt Length: 48.0mm Info: top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 77.00mm is STD Compression Height: 28.5mm Length: 51.2mm Recess Depth: +2.7/-3.5mm Bolt d.: 20.0mm Bolt Length: 48.0mm Info: top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 84.00mm is STD Compression Height: 47.0mm Length: 73.0mm Recess Depth: -4.6/-15.2mm Recess Diameter: 47.5mm Bolt d.: 32.0mm Bolt Length: 64.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.75x1.75x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 84.50mm is STD Compression Height: 42.0mm Length: 65.9mm Recess Depth: -4.6/-14.4mm Bolt d.: 28.0mm Bolt Length: 62.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.75x1.75x2.00mm

Package contains: 4 pistons with rings, pins Cyl.Bore: 84.50mm is STD Compression Height: 47.0mm Length: 73.0mm Recess Depth: -4.6/-14.4mm Bolt d.: 32.0mm Bolt Length: 64.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.75x1.75x2.00mm

Package contains: 6 pistons with rings, pins Cyl.Bore: 84.00mm is STD Compression Height: 47.0mm Length: 73.0mm Recess Depth: -4.7/-14.5mm Recess Diameter: 47.5mm Bolt d.: 32.0mm Bolt Length: 64.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.75x1.75x2.00mm

Package contains: 6 pistons with rings, pins Cyl.Bore: 84.00mm is STD Compression Height: 33.15mm Length: 52.15mm Recess Depth: +0.75mm Bolt d.: 22.0mm Bolt Length: 54.0mm Info: top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

Crankshaft: 49.975 / 49.990mm Housing: 53.599 / 53.619mm Max Wall Thickness: 1,801mm Max Length: 18,199mm Quantity: for 1 journal only

Crankshaft: 49.99 / 49.97mm Housing: 53.62 / 53.60mm Max Wall Thickness: 1,801mm Max Length: 18,2mm Quantity: 4

More details coming soon.

More details coming soon.
