Component Number: 18515; 18652; 29824/04 Quantity: 3 Thickness [mm] 18515: 3,55 Height [mm] 18515: 1,5 Material 18515: Cast Iron with Ductile Iron Surface 18515: Chromed; Phosphatized Cylinder Piston Diameter [mm] 18515: 81 Thickness [mm] 18652: 3,55 Height [mm] 18652: 1,75 Surface 18652: Phosphatized Cylinder Piston Diameter [mm] 18652: 81 Thickness [mm] 29824...

Bore: 96.00mm Top ring: 2.00mm 2nd ring: 1.50mm 3rd ring: 3.00mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 47.758 / 47.778mm Housing bore: 50.600 / 50.612mm Wall thickness: 1.406mm Bearing width: 19.00mm

Position: Crankshaft Quantity: 7 pairs Shaft diameter: 2.502mm / Housing bore: 57.958 / 57.978mm Wall thickness: 18.50mm Bearing width: St/B/G

Position: Crankshaft Quantity: 6 pairs Shaft diameter: 2.502mm / Housing bore: 57.958 / 57.978mm Wall thickness: 18.50mm Bearing width: St/B/G

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 47.758 / 47.778mm Housing bore: 50.600 / 50.619mm Wall thickness: 1.406mm Bearing width: 19.00mm

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 53.958 / 53.978mm Housing bore: 59.000 / 59.019mm Wall thickness: 2.502mm Bearing width: 18.50mm Position: Crankshaft Quantity: 1 pair Shaft diameter: 53.958 / 53.978mm Housing bore: 59.000 / 59.019mm Wall thickness: 2.502mm Bearing width: 18.50mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 54.971 / 54.990mm Housing bore: 57.800 / 57.819mm Wall thickness: 1.397mm Bearing width: 17.60mm

Bearing structure: Tri-Metal; Number in pack: 16

Bearing structure: Tri-Metal; Number in pack: 16

Cyl.Bore: 77.51mm Compression Height: 41.45mm Length: 71.45mm Recess Depth 1: 1.6mm Component No.: 32922, 39240, 35517 Bolt d.: 24mm Bolt Length: 64mm Rep. Stage: 1,00 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 80.01mm Compression Height: 39.4mm Length: 65.7mm Recess Depth 1: 1.9mm Component No.: 80009, 80006, 80002 Bolt d.: 24mm Bolt Length: 64mm Rep. Stage: 0.50
