Bore: 70.00mm Length: 62.4 mm Compression Height: 40.43 mm Pin Length: 56.7 mm Pin Diameter: 23 mm Recess Depth 1: 12.4 mm Recess Diameter: 37 mm Top Land Height: 7.5 mm Production Number: 69 L 46 Piston rings: 1.50x1.50x2.00mm

Bore: 70.00mm Length: 62.4 mm Compression Height: 40.43 mm Pin Length: 56.7 mm Pin Diameter: 23 mm Recess Depth 1: 12.4 mm Recess Diameter: 37 mm Top Land Height: 7.5 mm Production Number: 69 L 46 Piston rings: 1.50x1.50x2.00mm

Bore: 90.83mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 91.33mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 90.80mm Top ring: 1.60mm 2nd ring: 2.00mm 3rd ring: 4.00mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 42.582 / 42.600mm Housing bore: 45.734 / 45.744mm Wall thickness: 1.552mm Bearing width: 20.00mm

Component Number: 63558; 66236; 66237 Quantity: 3 Thickness [mm] 63558: 2,7 Height [mm] 63558: 2 Material 63558: Cast Iron with Ductile Iron Surface 63558: Blank; Chromed Cylinder Piston Diameter [mm] 63558: 69,6 Thickness [mm] 66236: 2,85 Height [mm] 66236: 1,5 Material 66236: Cast Iron with Ductile Iron Surface 66236: Blank; Diamond-coated Cylinder Piston...

Bolt length [mm]: 72,8 Bolt Ø [mm]: 24 Component Number: 45981; 71287; 71290 Compression Height [mm]: 41,55 Cylinder Piston Diameter [mm]: 91,83 Length [mm]: 69,55 Oversize [mm]: 1,00 Production Number: 091005 Quantity: 3 Thickness [mm] 45981: 4,5 Height [mm] 45981: 4 Material 45981: Steel Surface 45981: Chromed Cylinder Piston Diameter [mm] 45981:...

Bearing structure: Bi-Metal; Number in pack: 2

Bearing structure: Bi-Metal; Number in pack: 2

Bearing structure: Bi-Metal; Number in pack: 4

Bearing structure: Tri-Metal; Number in pack: 6
