Bore: 79.00mm (stock 79.00mm) Stroke: 81.40mm Compression height: 28.60mm Compression ratio: 10.1 Pin: 21mm Rings: 1.20x1.20x2.00mm Hard Anodized Top Ring Groove For Extreme Duty Applications Crown volume: -6.0cc Weight: 284g Alloy: 2618 Clearance guide: Measuring point: .250 Min: .0016 Max: .0023/td> Package: 4 pistons with rings and pins Warning: check...

Cyl.Bore: 79.00mm is STD Compression Height: 28.6mm Length: 54.0mm Recess Depth: +6.4/-5.2mm Bolt d.: 21.0mm Bolt Length: 46.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.045mm when measured at 10.0mm above the skirt Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 79.00mm is STD Compression Height: 28.6mm Length: 54.0mm Recess Depth: +6.4/-5.2mm Bolt d.: 21.0mm Bolt Length: 46.0mm Info: Alfin and with oil gallery, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.045mm when measured at 10.0mm above the skirt Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 87.50mm is STD Compression Height: 32.8mm Length: 55.8mm Recess Depth: +2.0/-4.3mm Bolt d.: 22.5mm Bolt Length: 56.0mm Info: head, top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Piston size: 82.00mm; Ring size: 2.00x1.75x2.00mm

Inner diameter (B): 78.50mm for 79.00mm Outside diameter (O): 84.35mm Flange outside diameter (F): 89.00mm Flange height (H): 20.00mm Total length (L): 130.00mm

Bolt length [mm]: 56 Bolt Ø [mm]: 22,5 Component Number: 86968 Compression Height [mm]: 32,8 Cylinder Piston Diameter [mm]: 87,515 Length [mm]: 53,8 Piston protrusion [mm]: 2,19 Production Number: 087144 Quantity: 1 Thickness [mm] 86968: 3,4 Height [mm] 86968: 1,2 Material 86968: Grey Cast Iron Surface 86968: Phosphatized Cylinder Piston Diameter [mm]...

Bolt length [mm]: 61 Bolt Ø [mm]: 26 Component Number: 66270; 66271; 66272 Compression Height [mm]: 41,7 Cylinder Piston Diameter [mm]: 75,6 Length [mm]: 65,15 Oversize [mm]: 0,60 Production Number: 075259 Quantity: 3 Recess Depth 1 [mm]: 13,9 Recess Diameter [mm]: 45 Thickness [mm] 66270: 3,1 Height [mm] 66270: 2,5 Material 66270: Cast Iron with Ductile...

Component Number: 62509; 66124; 66125 Quantity: 3 Thickness [mm] 62509: 3,3 Height [mm] 62509: 1,95 Material 62509: Grey Cast Iron Surface 62509: Phosphatized Cylinder Piston Diameter [mm] 62509: 75 Thickness [mm] 66124: 3,1 Height [mm] 66124: 2,5 Material 66124: Cast Iron with Ductile Iron Surface 66124: Blank; Chrome ceramic coated Cylinder Piston Diameter...

Bore: 81.40mm Top ring: 2.00mm 2nd ring: 1.75mm 3rd ring: 2.00mm
