Crankshaft: 47.78 / 47.76mm Housing: 50.61 / 50.60mm Max Wall Thickness: 1,401mm Max Length: 20mm Quantity: 4

Position: Crankshaft Quantity: 1 pairs Shaft diameter: 53.958 / 53.978mm Housing bore: 59.000 / 59.010mm Wall thickness: 2.502mm Bearing width: 18.50mm Position: Crankshaft Quantity: 4 pair Shaft diameter: 53.958 / 53.978mm Housing bore: 59.000 / 59.010mm Wall thickness: 2.502mm Bearing width: 18.50mm

Cyl.Bore: 80.00mm Compression Height: 45.05mm Length: 67.55mm Recess Depth 1: 10.7mm Recess Diameter: 49mm Component No.: 65956, 62759, 62758 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 47.758 / 47.778mm Housing bore: 50.600 / 50.612mm Wall thickness: 1.404mm Bearing width: 20.00mm

Number in pack: 1Big end width: 24.850 Big end diameter: 50.595-50.620 Center-to-center length: 152.000 Bore-to-bore length: 113.700 Pin end width: 22.000 Pin diameter: 26.020-26.035 Weight: 630 gr Specifications: Forged; Cracked; Tapered Torque: 50 Nm 2nd Torque option: 30 Nm + 90 degree

Crankshaft: 47.78 / 47.76mm Housing: 50.61 / 50.60mm Max Wall Thickness: 1.401mm Max Length: 20mm Quantity: 4

Crankshaft: 47.78 / 47.76mm Housing: 50.61 / 50.60mm Max Wall Thickness: 1.401mm Max Length: 20mm Quantity: 4

Crankshaft: 53.98 / 53.96mm Housing: 59.01 / 59.00mm Max Wall Thickness: 2.504mm Max Length: 18.5mm Quantity: 5
