Bolt length [mm]: 70 Bolt Ø [mm]: 30 Compression Height [mm]: 44,3 Cylinder Piston Diameter [mm]: 88,01 Length [mm]: 74,3 Production Number: 088129 Recess Depth 1 [mm]: 13,8 Recess Diameter [mm]: 47

Cyl.Bore: 88.51mm Compression Height: 42.3mm Length: 72.3mm Recess Depth 1: 14.1mm Valve Pocket Depth 1: 2.3mm Valve Pocket Depth 2: 1.9mm Recess Diameter: 46mm Component No.: 60559, 60555, 60557 Bolt d.: 30mm Bolt Length: 70mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Bolt length [mm]: 67 Bolt Ø [mm]: 31 Compression Height [mm]: 57 Cylinder Piston Diameter [mm]: 88,6 Length [mm]: 84 Oversize [mm]: 0,60 Production Number: 088122 Recess Depth 1 [mm]: 14,25 Recess Diameter [mm]: 49,2

Cyl.Bore: 92.50mm Compression Height: 28.1mm Length: 55.9mm Piston Crown Clearance: 7.8mm Recess Depth 1: 3mm Recess Diameter: 63.13mm Component No.: 62068, 61733, 62070 Standard Size [STD]: Bolt Ø: 22mm Bolt Length: 57mm Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 82.60mm Compression Height: 46.5mm Component No.: 62598, 63937, 63938 Rep. Stage: 0.60 Bolt Ø: 26mm Bolt Length: 61mm Production Number: 082278

Cyl.Bore: 90.405mm Compression Height: 53.5mm Length: 80.5mm Recess Depth 1: 16.3mm Recess Diameter: 49mm Component No.: 62212, 62209, 62211 Bolt d.: 32mm Bolt Length: 71mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 88.51mm Compression Height: 42.3mm Length: 72.3mm Recess Depth 1: 13.9mm Recess Diameter: 43.7mm Component No.: 60557, 60559, 60555 Bolt Ø: 30mm Bolt Length: 70mm Rep. Stage: 0.50

Cyl.Bore: 91.50mm Compression Height: 48.35mm Length: 81.85mm Recess Depth 1: 8.85mm Valve Pocket Depth 1: 1.15mm Component No.: 28311, 44316, 85173 Bolt d.: 26mm Bolt Length: 74mm

Cyl.Bore: 88.509mm Compression Height: 42.3mm Length: 72.3mm Recess Depth 1: 13.8mm Recess Diameter: 43.5mm Component No.: 60555, 60559, 60557 Bolt d.: 30mm Bolt Length: 70mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 80.00mm Compression Height: 45.05mm Length: 67.55mm Recess Depth 1: 10.7mm Recess Diameter: 49mm Component No.: 65956, 62759, 62758 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 80.01mm Compression Height: 45.55mm Length: 71.8mm Recess Depth 1: 17.75mm Valve Pocket Depth 1: 1mm Recess Diameter: 37.9mm Component No.: 86650, 80006, 80009 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 General Information: for cylinder 1-2

Cyl.Bore: 80.01mm Compression Height: 45.55mm Length: 71.8mm Recess Depth 1: 17.75mm Valve Pocket Depth 1: 1mm Recess Diameter: 37.9mm Component No.: 86650, 80006, 80009 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 General Information: for cylinder 3-4
