Bolt length [mm]: 72 Bolt Ø [mm]: 32 Component Number: 86838; 86842; 86845 Compression Height [mm]: 58,75 Cylinder Piston Diameter [mm]: 94,8 Length [mm]: 87,6 Oversize [mm]: 0,40 Production Number: 094056 Quantity: 3 Recess Depth 1 [mm]: 21,4 Recess Diameter [mm]: 39,3 Thickness [mm] 86838: 4,05 Height [mm] 86838: 2,5 Material 86838: Cast Iron with...

Position: Crankshaft Quantity: 6 pairs Shaft diameter: 2.502mm / Housing bore: 57.958 / 57.978mm Wall thickness: 18.50mm Bearing width: St/B/G

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 54.971 / 54.990mm Housing bore: 60.000 / 60.019mm Wall thickness: 2.49mm Bearing width: 24.00mm Position: Flanged bearing Quantity: 1 pair Shaft diameter: 54.971 / 54.990mm Housing bore: 60.000 / 60.019mm Wall thickness: 2.49mm Bearing width: 29.94mm

Possition: Crankshaft Quantity: 4 pairs Shaft diameter : 54.971 mm / 54.990 mm Housing bore: 60.000 mm / 60.019 mm Wall thickness: 2.5 mm Bearing width: 18.80 mm Possition: Crankshaft Quantity: 4 pc Shaft diameter : 54.971 mm / 54.990 mm Housing bore: 60.000 mm / 60.019 mm Wall thickness: 2.5 mm Bearing width: 18.80 mm Possition: Flanged...

Position: Crankshaft Quantity: 6 pairs Shaft diameter: 65.000 / 65.019mm Housing bore: / Wall thickness: 59.971mm Bearing width: 2.498mm Position: Flanged bearing Quantity: 1 pair Shaft diameter: 65.000 / 65.019mm Housing bore: 25.020 / 25.053mm Wall thickness: 59.971mm Bearing width: 2.498mm

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 59.971 / 59.990mm Housing bore: 65.000 / 65.019mm Wall thickness: 2.498mm Bearing width: 20.00mm Position: Crankshaft Quantity: 1 pc Shaft diameter: 59.971 / 59.990mm Housing bore: 65.000 / 65.019mm Wall thickness: 2.498mm Bearing width: 20.00mm Position: Flanged bearing Quantity: 1 pc Shaft...

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 65.000 / 65.019mm Housing bore: / Wall thickness: 59.971mm Bearing width: 2.498mm Position: Flanged bearings Quantity: 1 pair Shaft diameter: 65.000 / 65.019mm Housing bore: 25.020 / 25.053mm Wall thickness: 59.971mm Bearing width: 2.498mm

Position: Main bearing with one excentric oil hole Quantity: 6 pairs Shaft diameter: 59.971 / 59.990mm Housing bore: 65.000 / 65.019mm Wall thickness: 2.498mm Bearing width: 20.00mm Position: Flanged bearing Quantity: 1 pair Shaft diameter: 59.971 / 59.990mm Housing bore: 65.000 / 65.019mm Wall thickness: 2.498mm Bearing width: 24.94mm

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 49.980 / 50.001mm Housing bore: 55.000 / 55.019 Wall thickness: 2.497mm Bearing width: 17.30mm Position: Flanged bearings Quantity: 1 pair Shaft diameter: 49.980 / 50.001mm Housing bore: 55.000 / 55.019 Wall thickness: 2.497mm Bearing width: 23.95mm
