Cyl.Bore: 84.00mm is STD Compression Height: 46.95mm Length: 73.4mm Recess Depth: -4.65/-15.85mm Bolt d.: 32.0mm Bolt Length: 64.0mm Info: Alfin and with oil gallery, pin bushing inserted, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 85.00mm is STD Compression Height: 41.0mm Length: 61.0mm Recess Depth: -4.0/-15.0mm Bolt d.: 26.0mm Bolt Length: 58.5mm Info: alfin with oil gallery, skirt MoS2 treated Piston rings: 2.00x1.75x2.00mm

Cyl.Bore: 71.00mm is STD Compression Height: 26.2mm Length: 42.2mm Recess Depth: +2.6/-1.6mm Bolt d.: 17.0mm Bolt Length: 44.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.05mm when measured at 7.0mm above the skirt Piston rings: 1.00x1.00x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 26.3mm Length: 46.9mm Recess Depth: +2.6/-3.0mm Bolt d.: 17.0mm Bolt Length: 51.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated Piston rings: 1.00x1.00x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 25.7mm Length: 47.6mm Recess Depth: -5.7mm Bolt d.: 17.0mm Bolt Length: 51.0mm Info: 1st ring groove anodized, skirt MoS2 treated Piston rings: 1.00x1.00x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 28.4mm Length: 50.2mm Recess Depth: +4.9/-2.4mm Bolt d.: 19.5mm Bolt Length: 45.0mm Info: Alfin, skirt MoS2 treated, fits tapered connecting rod Recommended piston to bore clearance is 0.05mm when measured at 7.0mm above the skirt Piston rings: 1.20x1.00x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 39.9mm Length: 59.9mm Recess Depth: 5.0/-12.95mm Bolt d.: 26.0mm Bolt Length: 62.5mm Info: Alfin and with oil gallery, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.75x1.50x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 39.9mm Length: 59.9mm Recess Depth: 5.0/-12.95mm Bolt d.: 26.0mm Bolt Length: 62.5mm Info: Alfin and with oil gallery, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.75x1.50x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 39.9mm Length: 59.9mm Recess Depth: 5.0/-12.95mm Bolt d.: 26.0mm Bolt Length: 62.5mm Info: Alfin and with oil gallery, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.75x1.50x2.00mm

Cyl.Bore: 75.00mm is STD Compression Height: 39.9mm Length: 59.9mm Recess Depth: 5.0/-12.95mm Bolt d.: 26.0mm Bolt Length: 62.5mm Info: Alfin and with oil gallery, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.75x1.50x2.00mm

Cyl.Bore: 77.00mm is STD Compression Height: 26.3mm Length: 46.9mm Recess Depth: +2.6/-3.0mm Bolt d.: 17.0mm Bolt Length: 51.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated Piston rings: 1.20x1.50x2.00mm

Cyl.Bore: 77.00mm is STD Compression Height: 26.3mm Length: 46.9mm Recess Depth: +2.6/-3.0mm Bolt d.: 17.0mm Bolt Length: 51.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated Piston rings: 1.20x1.50x2.00mm
