Cyl.Bore: 71.50mm Compression Height: 29.25mm Length: 47.05mm Recess Depth 1: 6.3mm Component No.: 66150, 66149, 66148 Rep. Stage: 0.50

Bolt length [mm]: 68 Bolt Ø [mm]: 30 Component Number: 66181; 66182; 66183 Compression Height [mm]: 46,7 Cylinder Piston Diameter [mm]: 85 Length [mm]: 74,7 Production Number: 085236 Quantity: 3 Recess Depth 1 [mm]: 13,7 Recess Diameter [mm]: 50,5 Valve pocket depth 1 [mm]: 0,45 Valve pocket depth 2 [mm]: 0,45 Thickness [mm] 66181: 3,4 Height [mm] 66181:...

Bolt length [mm]: 66,85 Bolt Ø [mm]: 30 Component Number: 63268; 65892; 65894 Compression Height [mm]: 48,42 Cylinder Piston Diameter [mm]: 86,5 Length [mm]: 74,8 Oversize [mm]: 0,50 Production Number: 086218 Quantity: 3 Recess Depth 1 [mm]: 15,8 Recess Diameter [mm]: 46,9 Thickness [mm] 63268: 2,8 Height [mm] 63268: 2 Material 63268: Steel Surface...

Bolt length [mm]: 61 Bolt Ø [mm]: 26 Component Number: 66270; 66271; 66272 Compression Height [mm]: 41,7 Cylinder Piston Diameter [mm]: 75,6 Length [mm]: 65,15 Oversize [mm]: 0,60 Production Number: 075259 Quantity: 3 Recess Depth 1 [mm]: 13,9 Recess Diameter [mm]: 45 Thickness [mm] 66270: 3,1 Height [mm] 66270: 2,5 Material 66270: Cast Iron with Ductile...

Bolt length [mm]: 42 Bolt Ø [mm]: 19 Component Number: 66333; 66334; 66483 Compression Height [mm]: 28,94 Cylinder Piston Diameter [mm]: 71 Length [mm]: 46 Piston protrusion [mm]: 2,4 Production Number: 071076 Quantity: 3 Recess Depth 1 [mm]: 4,2 Thickness [mm] 66333: 2,6 Height [mm] 66333: 1,2 Material 66333: Steel Surface 66333: Blank;...

Cyl.Bore: 84.00mm Compression Height: 42mm Length: 66mm Recess Depth 1: 14.5mm Recess Diameter: 47.5mm Component No.: 66152, 66154, 66153 Standard Size [STD]: Bolt Ø: 28mm Bolt Length: 62mm Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 84.00mm Compression Height: 42mm Length: 66mm Recess Depth 1: 14.5mm Recess Diameter: 47.5mm Component No.: 66152, 66154, 66153 Standard Size [STD]: Bolt Ø: 28mm Bolt Length: 62mm Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 84.50mm Compression Height: 42mm Length: 66mm Recess Depth 1: 14.5mm Recess Diameter: 47.5mm Component No.: 66159, 66161, 66160 Bolt d.: 28mm Bolt Length: 62mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 84.50mm Compression Height: 42mm Length: 66mm Recess Depth 1: 14.5mm Recess Diameter: 47.5mm Component No.: 66159, 66161, 66160 Bolt d.: 28mm Bolt Length: 62mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Bolt length [mm]: 64 Bolt Ø [mm]: 32 Compression Height [mm]: 47,23 Cylinder Piston Diameter [mm]: 84,5 Length [mm]: 73 Oversize [mm]: 0,50 Production Number: 084261 Recess Depth 1 [mm]: 14,3 Recess Diameter [mm]: 47,5

Bolt length [mm]: 48 Bolt Ø [mm]: 20 Compression Height [mm]: 28,5 Cylinder Piston Diameter [mm]: 77,5 Length [mm]: 51,2 Oversize [mm]: 0,50 Piston protrusion [mm]: 2,7 Production Number: 077112 Recess Depth 1 [mm]: 6,3 Recess Diameter [mm]: 34,7 Valve pocket depth 1 [mm]: 3,3 Valve pocket depth 2 [mm]: 3,4

Bolt length [mm]: 66 Bolt Ø [mm]: 26 Component Number: 63506; 66234; 66235 Compression Height [mm]: 45,55 Cylinder Piston Diameter [mm]: 81,51 Length [mm]: 68,55 Oversize [mm]: 0,50 Production Number: 081204 Quantity: 3 Recess Depth 1 [mm]: 12,85 Recess Diameter [mm]: 50,88 Thickness [mm] 63506: 3,3 Height [mm] 63506: 2 Material 63506: Grey Cast...
