Cyl.Bore: 77.51mm Compression Height: 41.45mm Length: 71.45mm Recess Depth 1: 1.6mm Component No.: 32922, 39240, 35517 Bolt d.: 24mm Bolt Length: 64mm Rep. Stage: 1,00 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 86.50mm Compression Height: 30.43mm Length: 55.43mm Recess Depth 1: 0.85mm Valve Pocket Depth 1: 1.93mm Component No.: 70872, 70876, 70874 Bolt d.: 21mm Bolt Length: 61.5mm Rep. Stage: 0.50

Cyl.Bore: 82.01mm Compression Height: 30.45mm Length: 58.78mm Piston Crown Clearance: 4.33mm Recess Depth 1: 5.5mm Component No.: 18994, 18680, 18738 Bolt d.: 20mm Bolt Length: 57mm Rep. Stage: 1.00

Cyl.Bore: 80.01mm Compression Height: 39.4mm Length: 65.7mm Recess Depth 1: 1.9mm Component No.: 80009, 80006, 80002 Bolt d.: 24mm Bolt Length: 64mm Rep. Stage: 0.50

Cyl.Bore: 80.01mm Compression Height: 45.4mm Length: 71.7mm Recess Depth 1: 1.9mm Component No.: 80006, 80009, 80002 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50

Cyl.Bore: 81.51mm Compression Height: 33.1mm Length: 62.7mm Piston Crown Clearance: 0.6mm Component No.: 18680, 29839/04, 18649 Bolt d.: 20mm Bolt Length: 57mm Rep. Stage: 0.50

Cyl.Bore: 91.50mm Compression Height: 48.35mm Length: 81.85mm Recess Depth 1: 8.85mm Valve Pocket Depth 1: 1.15mm Component No.: 28311, 44316, 85173 Bolt d.: 26mm Bolt Length: 74mm

Cyl.Bore: 86.50mm Compression Height: 42.65mm Length: 89.04mm Piston Crown Clearance: 14.34mm Valve Pocket Depth 1: 3.8mm Component No.: 21117, 21110, 21119 Bolt d.: 23mm Bolt Length: 69mm Rep. Stage: 0.50

Bolt length [mm]: 55 Bolt Ø [mm]: 26 Component Number: 71880; 71881; 80117 Compression Height [mm]: 44,85 Cylinder Piston Diameter [mm]: 87,5 Length [mm]: 74,85 Oversize [mm]: 0,50 Production Number: 087068 Quantity: 3 Recess Depth 1 [mm]: 9,05 Valve pocket depth 1 [mm]: 1,05 Thickness [mm] 71880: 3,75 Height [mm] 71880: 3 Surface 71880: Chromed;...

Cyl.Bore: 80.01mm Compression Height: 45.55mm Length: 71.8mm Recess Depth 1: 17.75mm Valve Pocket Depth 1: 1mm Recess Diameter: 37.9mm Component No.: 86650, 80006, 80009 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 General Information: for cylinder 1-2

Cyl.Bore: 80.01mm Compression Height: 45.55mm Length: 71.8mm Recess Depth 1: 17.75mm Valve Pocket Depth 1: 1mm Recess Diameter: 37.9mm Component No.: 86650, 80006, 80009 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 General Information: for cylinder 3-4

Bolt length [mm]: 72 Bolt Ø [mm]: 32 Component Number: 86838; 86842; 86845 Compression Height [mm]: 58,75 Cylinder Piston Diameter [mm]: 94,8 Length [mm]: 87,6 Oversize [mm]: 0,40 Production Number: 094056 Quantity: 3 Recess Depth 1 [mm]: 21,4 Recess Diameter [mm]: 39,3 Thickness [mm] 86838: 4,05 Height [mm] 86838: 2,5 Material 86838: Cast Iron with...
