Conrod design: trapezoidal connecting rod Large connecting rod eye bore diameter: 51.6mm Small connecting rod eye diameter: 30.0mm Width big end: 22.0mm Width small end: 22.0mm Type of connecting rod separation: cracked Length: 149.0mm

Position: Crankshaft Quantity: 1 pc Shaft diameter: 54.690 / 54.715mm Housing bore: 59.000 / 59.019mm Wall thickness: 2.141mm Bearing width: 19.00mm Position: Crankshaft Quantity: 3 pcs Shaft diameter: 54.690 / 54.715mm Housing bore: 59.000 / 59.019mm Wall thickness: 2.141mm Bearing width: 19.00mm Position: Crankshaft Quantity: 4 pcs Shaft...

Position: Crankshaft Quantity: 5 pairs Shaft diameter: 51.485 / 51.500mm Housing bore: 55.497 / 55.511 m Wall thickness: 1.985mm Bearing width: 17.00mm

Bolt length [mm]: 66 Bolt Ø [mm]: 30 Component Number: 60485; 60486; 61438 Compression Height [mm]: 45,65 Cylinder Piston Diameter [mm]: 83,01 Length [mm]: 71,65 Production Number: 083092 Quantity: 3 Recess Depth 1 [mm]: 14,65 Recess Diameter [mm]: 43,4 Thickness [mm] 60485: 3,6 Height [mm] 60485: 2 Material 60485: Grey Cast Iron Surface 60485:...

Cyl.Bore: 83.51mm Compression Height: 45.65mm Length: 71.65mm Recess Depth 1: 14.65mm Recess Diameter: 43.4mm Component No.: 62409, 62408, 62591 Bolt d.: 30mm Bolt Length: 66mm Rep. Stage: 0.50 Fitment: for cylinder 1-3

Cyl.Bore: 83.51mm Compression Height: 45.65mm Length: 71.65mm Recess Depth 1: 14.65mm Recess Diameter: 43.4mm Component No.: 62409, 62408, 62591 Bolt d.: 30mm Bolt Length: 66mm Rep. Stage: 0.50 Fitment: for cylinder 1-3

Cyl.Bore: 83.51mm Compression Height: 45.65mm Length: 71.65mm Recess Depth 1: 14.65mm Recess Diameter: 43.4mm Component No.: 62591, 62409, 62408 Bolt d.: 30mm Bolt Length: 66mm Rep. Stage: 0.50 Fitment: for cylinder 3-6

Cyl.Bore: 83.51mm Compression Height: 45.65mm Length: 71.65mm Recess Depth 1: 14.65mm Recess Diameter: 43.4mm Component No.: 62591, 62409, 62408 Bolt d.: 30mm Bolt Length: 66mm Rep. Stage: 0.50 Fitment: for cylinder 3-6

Cyl.Bore: 83.50mm Oversize: 0.5mm Bolt d.: 30mm Component No.: 64051, 64054, 64057 Production Number: 83153 Compression Height: 48.5mm Recess Diameter: 49.4mm Bolt Length: 66mm Recess Depth 1: 13.2mm Valve Pocket Depth 1: 1.4mm Valve Pocket Depth 2: 1mm

Cyl.Bore: 83.50mm Oversize: 0.5mm Bolt d.: 30mm Component No.: 64051, 64054, 64057 Production Number: 83153 Compression Height: 48.5mm Recess Diameter: 49.4mm Bolt Length: 66mm Recess Depth 1: 13.2mm Valve Pocket Depth 1: 1.4mm Valve Pocket Depth 2: 1mm

Bolt length [mm]: 66 Bolt Ø [mm]: 30 Component Number: 64050; 64053; 64056 Compression Height [mm]: 48,5 Cylinder Piston Diameter [mm]: 83,25 Length [mm]: 75,5 Oversize [mm]: 0,25 Production Number: 083153 Quantity: 3 Recess Depth 1 [mm]: 13,2 Recess Diameter [mm]: 49,4 Thickness [mm] 64050: 3,55 Height [mm] 64050: 2 Material 64050: Cast Iron with Ductile...

Bolt length [mm]: 51 Bolt Ø [mm]: 20 Component Number: 66342; 66343; 66344 Compression Height [mm]: 33,8 Cylinder Piston Diameter [mm]: 83 Length [mm]: 53,8 Production Number: 083134 Quantity: 3 Recess Depth 1 [mm]: 7,2 Recess Diameter [mm]: 53,82 Thickness [mm] 66342: 3 Height [mm] 66342: 1,2 Material 66342: Steel Surface 66342: Blank; Physical Vapor...
