Production Number: 08683-101 Supplementary Article/Info 2: with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 15.85 mm Oversize: 0.5 mm Compression Height: 48.42 mm Height: 74.8 mm Cyl.Bore: 86.5 mm Bolt d.: 30 mm Recess Diameter: 46.9 mm Bolt Length: 66 mm Component No.: 08-427707-00 Machined: with cut-out for oil jet

Supplementary Article/Info 2: with piston ring carrier Recess Depth 1: 6.4 mm Piston Clearance: 0.05 mm Piston Protrusion: 1.85 mm Compression Height: 29 mm Height: 48 mm Cyl.Bore: 76.5 mm Bolt d.: 19 mm Bolt Length: 54 mm Valve Pocket Depth 1: 1 mm Valve Pocket Depth 2: 3.8 mm Component No.: 08-433900-00 Notice: Pistons to be replaced in Engine Sets only

Supplementary Article/Info 2: with piston ring carrier, for keystone connecting rod Recess Depth 1: 6.4 mm Oversize: 0.5 mm Piston Protrusion: 1.85 mm Compression Height: 29 mm Height: 48 mm Cyl.Bore: 77 mm Bolt d.: 19 mm Bolt Length: 53.5 mm Valve Pocket Depth 1: 1 mm Valve Pocket Depth 2: 3.8 mm Component No.: 08-433907-00 Notice: Pistons to be replaced in...

Supplementary Article/Info 2: for keystone connecting rod Recess Depth 1: 1.25 mm Compression Height: 31 mm Height: 48 mm Cyl.Bore: 74.5 mm Bolt d.: 19 mm Recess Diameter: 53.07 mm Bolt Length: 47 mm Valve Pocket Depth 1: 2.9 mm Valve Pocket Depth 2: 4.4 mm Component No.: 08-449500-00

Bore: 90.83mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 91.33mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 90.80mm Top ring: 1.60mm 2nd ring: 2.00mm 3rd ring: 4.00mm

Bore: 76.51mm Top ring: 1.20mm 2nd ring: 1.20mm 3rd ring: 2.00mm

Bore: 71.00mm Top ring: 1.00mm 2nd ring: 1.20mm 3rd ring: 2.00mm

Bore: 82.51mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 82.50mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 76.51mm Length: 50.2 mm Compression Height: 29.2 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 4.6 mm Valve Pocket Depth 1: 3.6 mm Valve Pocket Depth 2: 0.8 mm Surface: Hard Anodized Top Land Height: 5.7 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 76 L 135 Piston Clearance: 0.07 mm Piston rings: 1.20x1.20x2.00mm
