Position: Crankshaft Quantity: 1 pair Shaft diameter: 64.961 / 64.980mm Housing bore: 70.000 / 70.019mm Wall thickness: 2.508mm Bearing width: 19.85mm Position: Crankshaft Quantity: 1 pc Shaft diameter: 55.961 / 55.980mm Housing bore: 61.000 / 61.019mm Wall thickness: 2.508mm Bearing width: 18.85mm Position: Crankshaft Quantity: 3 pair Shaft...

Position: Main bearing, pos 1 Quantity: 1 pair Shaft diameter: 64.951 / 64.970mm Housing bore: 70.000 / 70.019mm Wall thickness: 2.508mm Bearing width: 19.85mm Position: Main bearing, pos 2 lower Quantity: 1 item Shaft diameter: 55.951 / 55.970mm Housing bore: 61.000 / 61.019mm Wall thickness: 2.508mm Bearing width: 18.85mm Position: Main bearing, pos 3, 4,...

Bore: 84.00mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Number in pack: 1Big end width: 20.850 Big end diameter: 53.600-53.616 Center-to-center length: 147.300 Bore-to-bore length: 110.500 Pin end width: 20.850 Pin diameter: 20.010-20.030 Weight: 495 gr Specifications: Forged; Cracked; Tapered Torque: 70 Nm

Crankshaft: 49.975 / 49.990mm Housing: 53.599 / 53.617mm Max Wall Thickness: 1.796mm Max Length: 17.6mm Quantity: 4

Crankshaft: 55.961 / 55.979 | 64.961 / 64.981 | 55.961 / 55.979mm Housing: 61.001 / 61.018 | 70.000 / 70.020 | 61.001 / 61.018mm Max Wall Thickness: 2.507 | 2.507 | 2.507mm Max Length: 18.699 | 19.7 | 22.4mm Quantity: 3 | 1 | 1
