Component Number: 62509; 66124; 66125 Quantity: 3 Thickness [mm] 62509: 3,3 Height [mm] 62509: 1,95 Material 62509: Grey Cast Iron Surface 62509: Phosphatized Cylinder Piston Diameter [mm] 62509: 75 Thickness [mm] 66124: 3,1 Height [mm] 66124: 2,5 Material 66124: Cast Iron with Ductile Iron Surface 66124: Blank; Chrome ceramic coated Cylinder Piston Diameter...

Bore: 71.90mm Top ring: 1.00mm 2nd ring: 1.20mm 3rd ring: 2.00mm

Number in pack: 1Big end width: 19.500 Big end diameter: 43.000-43.015 Center-to-center length: 137.000 Bore-to-bore length: 105.500 Pin end width: 15.300 Pin diameter: 20.015-20.024 Weight: 390 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 20 Nm + 40 degree

Crankshaft: 48.00 / 47.98 | 48.00 / 47.98mm Housing: 54.04 / 54.02 | 54.04 / 54.02mm Max Wall Thickness: 3.005 | 3.005mm Max Length: 16.1 | 23.9mm Quantity: 4 | 1

Piston rings: 1.00x1.20x2.00mm A: 27.400 B: 50.900 C: 8.700 CD: 43.700 D: 5.500 E: -3.200 F: -2.700 Pin: 20.00 x 46.80 Features: Hard Anodising

Piston rings: 1.20x1.20x2.00mm A: 34.850 B: 53.900 C: 9.300 E: -3.530 F: -3.470 CD: 53.500 Pin: 21.00 x 46.00 Features: Hard Anodising

Piston rings: 1.20x1.20x2.00mm A: 28.650 B: 54.000 C: 5.100 D: 6.350 E: -3.190 F: -2.430 CD: 53.500 Pin: 21.00 x 46.00 Features: Ring Carrier / Hard Anodising

Piston rings: 2.50x1.95x2.00mm A: 41.750 B: 65.200 C: 13.850 CD: 45.000 Pin: 26.00 x 61.00 Features: Ring Carrier / Oil Gallery / Oil Cut-Out

Piston rings: 2.50x1.95x2.00mm A: 41.750 B: 65.200 C: 13.850 CD: 45.000 Pin: 26.00 x 61.00 Features: Ring Carrier / Oil Gallery / Oil Cut-Out

Piston rings: 2.50x1.95x2.00mm A: 41.750 B: 65.200 C: 13.850 CD: 45.000 Pin: 26.00 x 61.00 Features: Ring Carrier / Oil Gallery / Oil Cut-Out

Piston rings: 2.50x1.95x2.00mm A: 41.750 B: 65.200 C: 13.850 CD: 45.000 Pin: 26.00 x 61.00 Features: Ring Carrier / Oil Gallery / Oil Cut-Out
