Component Number: 65920; 65922; 65924 Quantity: 3 Thickness [mm] 65920: 3,05 Height [mm] 65920: 2 Material 65920: Steel Surface 65920: Blank; Nitrified Cylinder Piston Diameter [mm] 65920: 79 Thickness [mm] 65922: 3,45 Height [mm] 65922: 2 Surface 65922: Chromed; Phosphatized Cylinder Piston Diameter [mm] 65922: 79 Thickness [mm] 65924: 3,3 Height [mm] 65924:...

Component Number: 63558; 66236; 66237 Quantity: 3 Thickness [mm] 63558: 2,7 Height [mm] 63558: 2 Material 63558: Cast Iron with Ductile Iron Surface 63558: Blank; Chromed Cylinder Piston Diameter [mm] 63558: 69,6 Thickness [mm] 66236: 2,85 Height [mm] 66236: 1,5 Material 66236: Cast Iron with Ductile Iron Surface 66236: Blank; Diamond-coated Cylinder Piston...

Component Number: 66310; 66311; 66316 Quantity: 3 Thickness [mm] 66310: 3 Height [mm] 66310: 1,5 Material 66310: Grey Cast Iron Surface 66310: Phosphatized Cylinder Piston Diameter [mm] 66310: 79 Thickness [mm] 66311: 2,9 Height [mm] 66311: 2 Material 66311: Cast Iron with Ductile Iron Surface 66311: Blank; Chromed Cylinder Piston Diameter [mm] 66311:...

Bearing structure: Tri-Metal; Number in pack: 10

Number in pack: 1Big end width: 23.700 Big end diameter: 45.725-45.750 Center-to-center length: 131.350 Bore-to-bore length: 96.975 Pin end width: 23.700 Pin diameter: 23.020-23.040 Weight: 450 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 20 Nm + 40 degree

Number in pack: 8Strengh class: 10.9 Thread: M8x1.00 Bolt lengh: 38 mm Bolt Head Design: Torx

Number in pack: 1Big end width: 21.850 Big end diameter: 46.000-46.012 Center-to-center length: 129.600 Bore-to-bore length: 97.100 Pin end width: 20.400 Pin diameter: 19.000-19.019 Weight: 420 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 10 Nm + 60 degree + 15 degree

Quantity Unit: Pair Oversize: 0.00 mm Surface: Galvanically coated for bearing clearance: from 0.027 mm, until 0.073 mm for housing diameter: from 45.734 mm, until 45.744 mm Width: from 19.75 mm, until 20 mm for wall: from 1.544 mm, until 1.554 mm for shaft diameter: from 42.582 mm, until 42.6 mm

Piston rings: 1.20x1.20x2.00mm A: 26.900 B: 48.550 CD: 54.600 D: 0.650 E: -1.350 F: -3.950 Pin: 18.00 x 52.30 Features: Hard Anodising

Piston rings: 1.20x1.20x2.00mm A: 25.800 B: 46.800 C: 1.600 CD: 52.000 E: -1.900 F: -3.830 Pin: 18.00 x 52.30 Features: Hard Anodising

Piston rings: 1.20x1.20x2.00mm A: 27.500 B: 45.100 Pin: 19.00 x 53.00 Features: Hard Anodising / Ring Carrier
