Position: Crankshaft Quantity: 5 pairs Shaft diameter: 51.485 / 51.500mm Housing bore: 55.497 / 55.511 m Wall thickness: 1.985mm Bearing width: 17.00mm

Possition: Connecting rod Quantity: 3 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 45.677 mm / 45.690 mm Wall thickness: 1.82 mm Bearing width: 17.30 mm

Possition: Connecting rod Quantity: 3 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 45.677 mm / 45.690 mm Wall thickness: 1.82 mm Bearing width: 17.30 mm

Possition: Crankshaft Quantity: 1 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm Possition: Crankshaft Quantity: 4 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm

Possition: Crankshaft Quantity: 1 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm Possition: Crankshaft Quantity: 4 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm

Possition: Crankshaft Quantity: 4 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm

Possition: Crankshaft Quantity: 4 pairs Shaft diameter : 41.990 mm / 42.010 mm Housing bore: 46.030 mm / 46.049 mm Wall thickness: 2.004 mm Bearing width: 16.10 mm

Bolt length [mm]: 60 Bolt Ø [mm]: 26 Component Number: 61824; 61826; 61828 Compression Height [mm]: 41,78 Cylinder Piston Diameter [mm]: 76 Length [mm]: 66 Production Number: 076191 Quantity: 3 Recess Depth 1 [mm]: 14 Recess Diameter [mm]: 39,7 Valve pocket depth 1 [mm]: 0,48 Valve pocket depth 2 [mm]: 0,28 Thickness [mm] 61824: 3,3 Height [mm] 61824:...

Cyl.Bore: 84.50mm Compression Height: 47.916mm Length: 76mm Recess Depth 1: 14.9mm Recess Diameter: 49.07mm Component No.: 62757, 62753, 62755 Bolt d.: 32mm Bolt Length: 65mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Bolt length [mm]: 60 Bolt Ø [mm]: 30 Component Number: 66486; 66487; 66488 Compression Height [mm]: 45,946 Cylinder Piston Diameter [mm]: 80,019 Length [mm]: 70,481 Production Number: 080340 Quantity: 3 Recess Depth 1 [mm]: 12,39 Recess Diameter [mm]: 46,5 Thickness [mm] 66486: 3,1 Height [mm] 66486: 2 Material 66486: Steel Surface 66486: Blank; Physical...

Conrod design: trapezoidal connecting rod Large connecting rod eye bore diameter: 47.61mm Small connecting rod eye diameter: 26.013mm Width big end: 21.9mm Width small end: 21.9mm Type of connecting rod separation: cracked Length: 133.75mm

Conrod design: trapezoidal connecting rod Large connecting rod eye bore diameter: 47.61mm Small connecting rod eye diameter: 26.013mm Width big end: 21.9mm Width small end: 21.9mm Type of connecting rod separation: cracked Length: 133.75mm
