Bearing structure: Tri-Metal; Number in pack: 8

Bore: 89.00mm Ring sizes: 1.75x2.00x4.00mm Oil ring type: 3 PC. FLEX-VENT

Bore: 89.00mm Top ring: 1.50mm 2nd ring: 2.00mm 3rd ring: 4.00mm

Component Number: 18658; 40775; 47313 Oversize [mm]: 0,25 Quantity: 3 Thickness [mm] 18658: 3,6 Height [mm] 18658: 1,75 Material 18658: Cast Iron with Ductile Iron Surface 18658: Chromed; Phosphatized Cylinder Piston Diameter [mm] 18658: 89,25 Thickness [mm] 40775: 4 Height [mm] 40775: 4 Surface 40775: Chromed Cylinder Piston Diameter [mm] 40775:...

Position: Crankshaft Quantity: 4 pairs Shaft diameter: 54.971 / 54.990mm Housing bore: 60.000 / 60.019mm Wall thickness: 2.49mm Bearing width: 24.00mm Position: Flanged bearing Quantity: 1 pair Shaft diameter: 54.971 / 54.990mm Housing bore: 60.000 / 60.019mm Wall thickness: 2.49mm Bearing width: 29.94mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 47.975 / 47.991mm Housing bore: 52.000 / 52.015mm Wall thickness: 1.993mm Bearing width: 20.00mm

Crankshaft: 47.99 / 47.98mm Housing: 52.01 / 52.00mm Max Wall Thickness: 1,994mm Max Length: 20mm Quantity: 4

Crankshaft: 54.99 / 54.97 | 54.99 / 54.97mm Housing: 60.02 / 60.00 | 60.02 / 60.00mm Max Wall Thickness: 2,489 | 2,489mm Max Length: See AVAILABLE SIZES | 24mm Quantity: 1 | 4

Width: 20 mm for bearing clearance from: 0.02 mm, until 0.08 mm for housing diameter from: 52 mm, until 52.015 mm for shaft diameter from: 47.975 mm, until 47.991 mm Component No.: 71-2182 Thickness: 1.993 mm
