Bolt length [mm]: 70 Bolt Ø [mm]: 28 Component Number: 83532; 83643; 85930 Compression Height [mm]: 46,705 Cylinder Piston Diameter [mm]: 85 Length [mm]: 80,705 Production Number: 085190 Quantity: 3 Recess Depth 1 [mm]: 15,4 Recess Diameter [mm]: 44,8 Valve pocket depth 1 [mm]: 0,52 Thickness [mm] 83532: 3,65 Height [mm] 83532: 3 Surface 83532: Blank;...

Bearing structure: Tri-Metal; Number in pack: 8

Bearing structure: Tri-Metal; Number in pack: 10

Number in pack: 1Big end width: 20.800 Big end diameter: 50.655-50.670 Center-to-center length: 136.800 Bore-to-bore length: 98.470 Pin end width: 20.800 Pin diameter: 26.020-26.032 Weight: 600 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 5 Nm + 10 Nm + 130 degree

Number in pack: 1Big end width: 20.800 Big end diameter: 50.655-50.670 Center-to-center length: 136.800 Bore-to-bore length: 98.470 Pin end width: 20.800 Pin diameter: 26.020-26.032 Weight: 600 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 5 Nm + 10 Nm + 130 degree

Number in pack: 1Big end width: 24.150 Big end diameter: 53.695-53.710 Center-to-center length: 145.000 Bore-to-bore length: 103.150 Pin end width: 24.150 Pin diameter: 30.020-30.035 Weight: 790 gr Specifications: Forged; Cracked; Tapered Torque: 60 Nm

A=48.705 B=74.705 C=13.475 CD=52.400 E=-0.450

A=41.700 B=65.300 C=13.250 CD=41.800 E=-1.200

A=41.700 B=65.300 C=13.250 CD=41.800 E=-1.200

A=41.700 B=65.300 C=13.250 CD=41.800 E=-1.200

A=41.700 B=65.300 C=13.250 CD=41.800 E=-1.200
