Supplementary Article/Info 2: for keystone connecting rod Recess Depth 1: 2 mm Compression Height: 33.3 mm Height: 52.7 mm Cyl.Bore: 82 mm Bolt d.: 22 mm Recess Diameter: 56.1 mm Bolt Length: 51.1 mm Valve Pocket Depth 1: 4.4 mm Valve Pocket Depth 2: 4.5 mm Component No.: 08-453400-00 Surface: Hard Anodized

Spanner Size: 14 mm Thread Size: M12 x 1.25 Thread Length: 26.5 mm Spark Plug: Iridium Middle Electrode, 1 - Earthed Electrode, Interference Suppression 5 kOhm, with gasket seat Spark Position: 4.7 mm Version: Bi-Hex

Piston rings: 1.20x1.50x2.00mm A: 31.300 B: 51.000 C: 2.2150 E: -4.900 F: -5.300 CD: 62.100 Pin: 22.00 x 55.00 Features: Ring Carrier

Piston rings: 1.20x1.50x2.00mm A: 31.300 B: 51.000 C: 2.2150 E: -4.900 F: -5.300 CD: 62.100 Pin: 22.00 x 55.00 Features: Ring Carrier

Piston rings: 1.20x1.50x2.00mm A: 31.300 B: 51.000 C: 2.2150 E: -4.900 F: -5.300 CD: 62.100 Pin: 22.00 x 55.00 Features: Ring Carrier

Piston rings: 1.20x1.50x2.00mm A: 31.300 B: 51.000 C: 2.2150 E: -4.900 F: -5.300 CD: 62.100 Pin: 22.00 x 55.00 Features: Ring Carrier

Piston size: 82.00mm; Ring size: 1.20x1.50x2.00mm

Piston size: 82.00mm; Ring size: 1.20x1.50x2.00mm

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A
