Cyl.Bore: 72.40mm Compression Height: 32.9mm Length: 50.9mm Recess Depth 1: 8.7mm Valve Pocket Depth 1: 2.9mm Valve Pocket Depth 2: 2.3mm Recess Diameter: 43mm Component No.: 67017, 67016, 67015 Bolt Ø: 20mm Bolt Length: 47mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 73.00mm Compression Height: 25.87mm Length: 44.18mm Recess Depth 1: 2.9mm Valve Pocket Depth 1: 1.87mm Valve Pocket Depth 2: 2.1mm Recess Diameter: 56.2mm Component No.: 66598, 66599, 66597 Bolt d.: 18mm Bolt Length: 48mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 74.51mm Compression Height: 30.84mm Length: 48.84mm Recess Depth 1: 5mm Component No.: 66844, 66842, 66843 Standard Size [STD]: Bolt d.: 19mm Bolt Length: 50mm Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 75.60mm Piston Clearance: 0.06mm Compression Height: 39.94mm Length: 59.94mm Recess Depth 1: 13.0mm Recess Diameter: 40.8mm Component No.: 100170000, 100180000, 100190000 Bolt d.: 26m Bolt Length: 62.5mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 75.60mm Piston Clearance: 0.06mm Compression Height: 39.94mm Length: 59.94mm Recess Depth 1: 13.0mm Recess Diameter: 40.8mm Component No.: 100170000, 100180000, 100190000 Bolt d.: 26m Bolt Length: 62.5mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 76.51mm Compression Height: 28.92mm Length: 49.92mm Recess Depth 1: 1.98mm Valve Pocket Depth 1: 2.2mm Valve Pocket Depth 2: 2.2mm Component No.: 85724, 84762, 82611 Standard Size [STD]: Bolt d.: 17mm Bolt Length: 54mm

Cyl.Bore: 76.51mm Compression Height: 29.27mm Length: 50.27mm Recess Depth 1: 4mm Valve Pocket Depth 1: 1.2mm Valve Pocket Depth 2: 2.7mm Recess Diameter: 68.32mm Component No.: 61205, 84762, 85724 Standard Size [STD]: Bolt d.: 17mm Bolt Length: 46mm

Cyl.Bore: 77.01mm Compression Height: 29.2mm Length: 50.21mm Piston Crown Clearance: 2mm Recess Depth 1: 4.6mm Valve Pocket Depth 1: 4mm Valve Pocket Depth 2: 2mm Component No.: 63597, 63593, 63595 Bolt d.: 19mm Bolt Length: 52mm Rep. Stage: 0.50

Cyl.Bore: 77.01mm Compression Height: 28.97mm Length: 49.97mm Piston Crown Clearance: 2mm Recess Depth 1: 4.57mm Valve Pocket Depth 1: 4mm Valve Pocket Depth 2: 1.3mm Component No.: 66038, 66040, 66039 Bolt d.: 19mm Bolt Length: 54mm Rep. Stage: 0.50

Cyl.Bore: 77.51mm Compression Height: 41.45mm Length: 71.45mm Recess Depth 1: 1.6mm Component No.: 32922, 39240, 35517 Bolt d.: 24mm Bolt Length: 64mm Rep. Stage: 1,00 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 80.00mm Compression Height: 45.05mm Length: 67.55mm Recess Depth 1: 10.7mm Recess Diameter: 49mm Component No.: 65956, 62759, 62758 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Cyl.Bore: 80.01mm Compression Height: 45.55mm Length: 71.8mm Recess Depth 1: 17.75mm Valve Pocket Depth 1: 1mm Recess Diameter: 37.9mm Component No.: 86650, 80006, 80009 Bolt d.: 26mm Bolt Length: 66mm Rep. Stage: 0.50 General Information: for cylinder 1-2
