Cyl.Bore: 82.50mm is STD Compression Height: 29.8mm Length: 55.9mm Recess Depth: +5.6/-4.8mm Bolt d.: 23.0mm Bolt Length: 51.0mm Info: Alfin, skirt MoS2 treated, fits tapered connecting rod, 3-piece oil ring Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 82.50mm is STD Compression Height: 29.8mm Length: 55.9mm Recess Depth: +5.6/-4.8mm Bolt d.: 23.0mm Bolt Length: 51.0mm Info: Alfin, skirt MoS2 treated, fits tapered connecting rod, 3-piece oil ring Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 82.50mm is STD Compression Height: 29.6mm Length: 50.1mm Recess Depth: -6.2mm Bolt d.: 23.0mm Bolt Length: 51.0mm Info: Alfin, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 82.50mm is STD Compression Height: 29.6mm Length: 50.1mm Recess Depth: -6.2mm Bolt d.: 23.0mm Bolt Length: 51.0mm Info: Alfin, skirt MOS2 treated, fits tapered connecting rod Piston rings: 1.20x1.20x2.00mm

Bore: 87.51mm (stock 87.51mm) Stroke: 94.00mm Compression height: 32.80mm Compression ratio: 9.5 Pin: 22.5mm Rings: 1.20x1.20x2.80mm Hard Anodized Top Ring Groove For Extreme Duty Applications Crown volume: -6.5cc Weight: 376g Alloy: 2618 Clearance guide: Measuring point: .395 Min: .0016 Max: .0023/td> Package: 4 pistons with rings and pins Warning: check...

Cyl.Bore: 81.00mm is STD Compression Height: 45.8mm Length: 68.8mm Recess Depth: -8.5/-13.5mm Bolt d.: 26.0mm Bolt Length: 66.0mm Info: Alfin, with oil gallery, skirt MOS2 treated, pin bushing inserted, fits tapered connecting rod Piston rings: 1.75x2.00x2.00mm

Cyl.Bore: 81.00mm is STD Compression Height: 45.7mm Length: 68.8mm Recess Depth: -9.0/-13.5mm Bolt d.: 26.0mm Bolt Length: 66.0mm Info: Alfin, with oil gallery, skirt MOS2 treated, pin bushing inserted, fits tapered connecting rod Piston rings: 1.75x2.00x2.00mm

Cyl.Bore: 81.00mm is STD Compression Height: 45.8mm Length: 68.8mm Recess Depth: -7.9/-12.8mm Bolt d.: 26.0mm Bolt Length: 66.0mm Info: Alfin, with oil gallery, skirt MOS2 treated, pin bushing inserted, fits tapered connecting rod Piston rings: 1.75x2.00x2.00mm

Cyl.Bore: 82.50mm is STD Compression Height: 29.6mm Length: 50.1mm Recess Depth: -6.2mm Bolt d.: 23.0mm Bolt Length: 53.0mm Info: Alfin, skirt MoS2 treated, fits tapered connecting rod, 2-piece oil ring Piston rings: 1.20x1.20x2.00mm

Cyl.Bore: 82.50mm is STD Compression Height: 29.6mm Length: 50.1mm Recess Depth: -6.2mm Bolt d.: 23.0mm Bolt Length: 53.0mm Info: Alfin, skirt MoS2 treated, fits tapered connecting rod, 2-piece oil ring Piston rings: 1.20x1.20x2.00mm

Bolt length [mm]: 80 Bolt Ø [mm]: 42 Component Number: 61534; 80096; 81927 Compression Height [mm]: 64,4 Cylinder Piston Diameter [mm]: 102 Length [mm]: 102,4 Production Number: 102046 Quantity: 3 Recess Depth 1 [mm]: 13,9 Recess Diameter [mm]: 73,23 Thickness [mm] 61534: 4,45 Height [mm] 61534: 3,5 Material 61534: Cast Iron with Ductile Iron Surface...

Bolt length [mm]: 66 Bolt Ø [mm]: 30 Component Number: 60485; 60486; 61438 Compression Height [mm]: 45,65 Cylinder Piston Diameter [mm]: 83,01 Length [mm]: 71,65 Production Number: 083092 Quantity: 3 Recess Depth 1 [mm]: 14,65 Recess Diameter [mm]: 43,4 Thickness [mm] 60485: 3,6 Height [mm] 60485: 2 Material 60485: Grey Cast Iron Surface 60485:...
