Supplementary Article/Info 2: with piston ring carrier, for keystone connecting rod Recess Depth 1: 6.4 mm Oversize: 0.5 mm Piston Protrusion: 1.85 mm Compression Height: 29 mm Height: 48 mm Cyl.Bore: 77 mm Bolt d.: 19 mm Bolt Length: 53.5 mm Valve Pocket Depth 1: 1 mm Valve Pocket Depth 2: 3.8 mm Component No.: 08-433907-00 Notice: Pistons to be replaced in...

Component No.: 08-434600-00

Production Number: 0849D-408A Emission Standard: Euro 6 Supplementary Article/Info 2: with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 15.35 mm Piston Clearance: 0.069 mm Compression Height: 46 mm Height: 70 mm Cyl.Bore: 84 mm Bolt d.: 30 mm Recess Diameter: 47.62 mm Bolt Length: 63 mm Component No.:...

Production Number: 0849D-408A Emission Standard: Euro 6 Supplementary Article/Info 2: with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 15.35 mm Oversize: 0.5 mm Piston Clearance: 0.069 mm Compression Height: 46 mm Height: 70 mm Cyl.Bore: 84.5 mm Bolt d.: 30 mm Recess Diameter: 47.62 mm Bolt Length: 63.45 mm Component...

Supplementary Article/Info 2: with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 12.71 mm Recess Depth 2: 4.9 mm Oversize: 0.6 mm Compression Height: 46.61 mm Height: 72 mm Cyl.Bore: 85.6 mm Bolt d.: 30 mm Recess Diameter: 51.3 mm Bolt Length: 72 mm Component No.: 08-443108-00 Machined: with cut-out for oil jet Piston...

Supplementary Article/Info 2: with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 12.71 mm Recess Depth 2: 4.9 mm Oversize: 0.6 mm Compression Height: 46.61 mm Height: 72 mm Cyl.Bore: 85.6 mm Bolt d.: 30 mm Recess Diameter: 51.3 mm Bolt Length: 72 mm Component No.: 08-443108-00 Machined: with cut-out for oil jet Piston...

Supplementary Article/Info 2: for keystone connecting rod Recess Depth 1: 1.25 mm Compression Height: 31 mm Height: 48 mm Cyl.Bore: 74.5 mm Bolt d.: 19 mm Recess Diameter: 53.07 mm Bolt Length: 47 mm Valve Pocket Depth 1: 2.9 mm Valve Pocket Depth 2: 4.4 mm Component No.: 08-449500-00

Supplementary Article/Info 2: with piston ring carrier, for keystone connecting rod Recess Depth 1: 9.3 mm Compression Height: 34.85 mm Height: 53.9 mm Cyl.Bore: 79 mm Bolt d.: 21 mm Recess Diameter: 53.5 mm Bolt Length: 49 mm Valve Pocket Depth 1: 3.53 mm Valve Pocket Depth 2: 3.47 mm Component No.: 08-452800-10

Supplementary Article/Info 2: with bush for piston pin boss, with cooling duct, with piston ring carrier, for keystone connecting rod Recess Depth 1: 14.4 mm Oversize: 0.5 mm Compression Height: 48.4 mm Height: 73.2 mm Cyl.Bore: 84.51 mm Bolt d.: 30 mm Recess Diameter: 48.23 mm Bolt Length: 63.65 mm Valve Pocket Depth 1: 0.06 mm Component No.:...

Supplementary Article/Info 2: for keystone connecting rod Recess Depth 1: 2 mm Compression Height: 33.3 mm Height: 52.7 mm Cyl.Bore: 82 mm Bolt d.: 22 mm Recess Diameter: 56.1 mm Bolt Length: 51.1 mm Valve Pocket Depth 1: 4.4 mm Valve Pocket Depth 2: 4.5 mm Component No.: 08-453400-00 Surface: Hard Anodized

Bore: 87.50mm Length: 80.6 mm Compression Height: 48.6 mm Pin Length: 75 mm Pin Diameter: 25 mm Recess Depth 1: 1.3 mm Surface: Tin-plated Top Land Height: 13.4 mm Production Number: 86 V 13 Piston Clearance: 0.02 mm Piston rings: 2.00x2.50x4.00mm

Bore: 70.00mm Length: 62.4 mm Compression Height: 40.43 mm Pin Length: 56.7 mm Pin Diameter: 23 mm Recess Depth 1: 12.4 mm Recess Diameter: 37 mm Top Land Height: 7.5 mm Production Number: 69 L 46 Piston rings: 1.50x1.50x2.00mm
