Bore: 70.00mm Length: 62.4 mm Compression Height: 40.43 mm Pin Length: 56.7 mm Pin Diameter: 23 mm Recess Depth 1: 12.4 mm Recess Diameter: 37 mm Top Land Height: 7.5 mm Production Number: 69 L 46 Piston rings: 1.50x1.50x2.00mm

Bore: 84.51mm Length: 73.2 mm Compression Height: 48.4 mm Pin Length: 63.65 mm Pin Diameter: 30 mm Recess Depth 1: 14.4 mm Recess Diameter: 48.23 mm Top Land Height: 9.6 mm Info: with cut-out for oil jet, coated Production Number: 84 L 195 Piston rings: 2.00x2.00x2.00mm

Bore: 90.83mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 91.33mm Length: 69.6 mm Compression Height: 41.55 mm Pin Length: 68.8 mm Pin Diameter: 24 mm Surface: Tin-plated Top Land Height: 8.5 mm Production Number: 90 V 118 Piston Clearance: 0.032 mm Piston rings: 1.60x2.00x4.00mm

Bore: 72.20mm Length: 47.3 mm Compression Height: 31.24 mm Pin Length: 49 mm Pin Diameter: 20 mm Valve Pocket Depth 1: 2 mm Valve Pocket Depth 2: 2.7 mm Top Land Height: 5.5 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 72 L 71 Piston Clearance: 0.05 mm Piston rings: 1.20x1.50x2.00mm

Bore: 72.45mm Length: 47.3 mm Compression Height: 31.24 mm Pin Length: 49 mm Pin Diameter: 20 mm Valve Pocket Depth 1: 2 mm Valve Pocket Depth 2: 2.7 mm Top Land Height: 5.5 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 72 L 71 Piston Clearance: 0.05 mm Piston rings: 1.20x1.50x2.00mm

Bore: 72.70mm Length: 47.3 mm Compression Height: 31.24 mm Pin Length: 49 mm Pin Diameter: 20 mm Valve Pocket Depth 1: 2 mm Valve Pocket Depth 2: 2.7 mm Top Land Height: 5.5 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 72 L 71 Piston Clearance: 0.05 mm Piston rings: 1.20x1.50x2.00mm

Bore: 81.01mm Length: 69.8 mm Compression Height: 45.75 mm Pin Length: 66 mm Pin Diameter: 26 mm Recess Depth 1: 16.6 mm Recess Diameter: 46 mm Valve Pocket Depth 1: 1.3 mm Valve Pocket Depth 2: 1.3 mm Machined: with cut-out for oil jet Surface: Coated Supplementary Article/Info 2: with piston ring carrier, with cooling duct Top Land Height: 12...

Bore: 76.51mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 76.76mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 77.01mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 76.51mm Length: 50.2 mm Compression Height: 29.2 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 4.6 mm Valve Pocket Depth 1: 3.6 mm Valve Pocket Depth 2: 0.8 mm Surface: Hard Anodized Top Land Height: 5.7 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 76 L 135 Piston Clearance: 0.07 mm Piston rings: 1.20x1.20x2.00mm
