Cyl.Bore: 92.90mm is STD Compression Height: 32.3mm Length: 53.3mm Recess Depth: +2.5/-2.7mm Recess Diameter: 56.8mm Bolt d.: 24.0mm Bolt Length: 56.0mm Info: Top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

Cyl.Bore: 85.00mm is STD Compression Height: 41.0mm Length: 61.0mm Recess Depth: -4.0/-15.0mm Bolt d.: 26.0mm Bolt Length: 58.5mm Info: alfin with oil gallery, skirt MoS2 treated Piston rings: 2.00x1.75x2.00mm

Contains: for 8cyl. Bore: 92.90mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 87.50mm Length: 80.6 mm Compression Height: 48.6 mm Pin Length: 75 mm Pin Diameter: 25 mm Recess Depth 1: 1.3 mm Surface: Tin-plated Top Land Height: 13.4 mm Production Number: 86 V 13 Piston Clearance: 0.02 mm Piston rings: 2.00x2.50x4.00mm

Quantity Unit: Pair Oversize: 0.00 mm for bearing clearance: from 0.006 mm, until 0.03 mm for housing diameter: from 51.6 mm, until 51.619 mm Width: from 21.5 mm, until 21.8 mm for wall: from 1.805 mm, until 1.811 mm for shaft diameter: from 47.95 mm, until 47.965 mm

Bore: 83.00mm Top ring: 2.00mm 2nd ring: 1.75mm 3rd ring: 2.00mm

Bore: 82.00mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 83.00mm Top ring: 1.20mm 2nd ring: 1.00mm 3rd ring: 2.00mm

Bore: 83.00mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 82.00mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.50mm

Bore: 83.00mm Top ring: 2.00mm 2nd ring: 2.00mm 3rd ring: 2.00mm

Bore: 83.50mm Top ring: 2.00mm 2nd ring: 2.00mm 3rd ring: 2.00mm
