Position: Main bearing, pos 1 Quantity: 1 pair Shaft diameter: 64.951 / 64.970mm Housing bore: 70.000 / 70.019mm Wall thickness: 2.508mm Bearing width: 19.85mm Position: Main bearing, pos 2 lower Quantity: 1 item Shaft diameter: 55.951 / 55.970mm Housing bore: 61.000 / 61.019mm Wall thickness: 2.508mm Bearing width: 18.85mm Position: Main bearing, pos 3, 4,...

Bore: 84.00mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Crankshaft: 49.975 / 49.990mm Housing: 53.599 / 53.617mm Max Wall Thickness: 1,796mm Max Length: 17,6mm Quantity: 4

Cyl.Bore: 77.00mm is STD Compression Height: 28.5mm Length: 51.2mm Recess Depth: +2.7/-3.5mm Bolt d.: 20.0mm Bolt Length: 48.0mm Info: top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

More details coming soon.

Cyl.Bore: 77.00mm is STD Compression Height: 28.5mm Length: 51.2mm Recess Depth: +2.7/-3.5mm Bolt d.: 20.0mm Bolt Length: 48.0mm Info: top and 2nd ring lands anodized, skirt MoS2 treated, fits tapered connecting rod Piston rings: 1.20x1.50x2.00mm

Crankshaft: 55.961 / 55.979 | 64.961 / 64.981 | 55.961 / 55.979mm Housing: 61.001 / 61.018 | 70.000 / 70.020 | 61.001 / 61.018mm Max Wall Thickness: 2,507 | 2,507 | 2,507mm Max Length: 18,699 | 19,7 | 22,4mm Quantity: 3 | 1 | 1

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A

Crankshaft: 55.961 / 55.979 | 64.961 / 64.981 | 55.961 / 55.979mm Housing: 61.001 / 61.018 | 70.000 / 70.020 | 61.001 / 61.018mm Max Wall Thickness: 2,507 | 2,507 | 2,507mm Max Length: 18,699 | 19,7 | 22,4mm Quantity: 3 | 1 | 1

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A

Bore: 82.00mm Ring sizes: 1.20x1.50x2.00mm Oil ring type: N/A
