Bearing structure: Tri-Metal; Number in pack: 10

Bearing structure: Tri-Metal; Number in pack: 12

Number in pack: 1Big end width: 20.800 Big end diameter: 50.655-50.670 Center-to-center length: 136.800 Bore-to-bore length: 98.470 Pin end width: 20.800 Pin diameter: 26.020-26.032 Weight: 600 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 5 Nm + 10 Nm + 130 degree

Number in pack: 1Big end width: 20.800 Big end diameter: 50.655-50.670 Center-to-center length: 136.800 Bore-to-bore length: 98.470 Pin end width: 20.800 Pin diameter: 26.020-26.032 Weight: 600 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 5 Nm + 10 Nm + 130 degree

Number in pack: 1Big end width: 23.700 Big end diameter: 45.725-45.750 Center-to-center length: 131.350 Bore-to-bore length: 96.975 Pin end width: 23.700 Pin diameter: 23.020-23.040 Weight: 450 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 20 Nm + 40 degree

Number in pack: 8Strengh class: 10.9 Thread: M8x1.00 Bolt lengh: 38 mm Bolt Head Design: Torx

Number in pack: 1Big end width: 26.650 Big end diameter: 53.895-53.920 Center-to-center length: 145.000 Bore-to-bore length: 103.030 Pin end width: 26.650 Pin diameter: 30.020-30.040 Weight: 740 gr Specifications: Forged; Cracked; Tapered Torque: 60 Nm 2nd Torque option: 25 Nm + 60 degree Notice: with bearing locating lug (without BMY1504)

Number in pack: 1Big end width: 25.650 Big end diameter: 53.895-53.920 Center-to-center length: 145.000 Bore-to-bore length: 103.030 Pin end width: 25.650 Pin diameter: 30.020-30.040 Weight: 740 gr Specifications: Forged; Cracked; Tapered Torque: 70 Nm 2nd Torque option: 25 Nm + 60 degree Notice: without bearing locating lug (with BMY1404)

Number in pack: 1Big end width: 24.500 Big end diameter: 52.995-53.020 Center-to-center length: 140.000 Bore-to-bore length: 101.000 Pin end width: 24.500 Pin diameter: 25.020-25.035 Weight: 600 gr Specifications: Forged; Cracked; Tapered Torque: 60 Nm 2nd Torque option: 25 Nm + 60 degree

Number in pack: 1Big end width: 21.850 Big end diameter: 46.000-46.012 Center-to-center length: 129.600 Bore-to-bore length: 97.100 Pin end width: 20.400 Pin diameter: 19.000-19.019 Weight: 420 gr Specifications: Forged; Cracked; Tapered Torque: 45 Nm 2nd Torque option: 10 Nm + 60 degree + 15 degree
