Position: Crankshaft Quantity: 5 pairs Shaft diameter: 51.485 / 51.500mm Housing bore: 55.497 / 55.511 m Wall thickness: 1.985mm Bearing width: 17.00mm

Cyl.Bore: 84.50mm Compression Height: 47.916mm Length: 76mm Recess Depth 1: 14.9mm Recess Diameter: 49.07mm Component No.: 62757, 62753, 62755 Bolt d.: 32mm Bolt Length: 65mm Rep. Stage: 0.50 Connecting Rod Design: Trapezoidal Connecting Rod

Position: Connecting rod Quantity: 4 pcs Shaft diameter: 56.520 / 56.535mm Housing bore: 60.333 / 60.345mm Wall thickness: 1.9mm Bearing width: 24.70mm Position: Connecting rod Quantity: 4 pc Shaft diameter: 56.520 / 56.535mm Housing bore: 60.333 / 60.345mm Wall thickness: 1.872mm Bearing width: 24.70mm

Position: Connecting rod Quantity: 4 pcs Shaft diameter: 48.000 / 48.020mm Housing bore: 51.587 / 51.600mm Wall thickness: 1.768mm Bearing width: 20.50mm Position: Connecting rod Quantity: 4 pcs Shaft diameter: 48.000 / 48.020mm Housing bore: 51.587 / 51.600mm Wall thickness: 1.768mm Bearing width: 20.50mm

Position: Crankshaft Quantity: 5 pairs Shaft diameter: 48.000 / 48.011mm Housing bore: 51.935 / 51.943mm Wall thickness: 1.95mm Bearing width: 19.50mm

Position: Crankshaft Quantity: 5 pairs Shaft diameter: 48.000 / 48.011mm Housing bore: 51.935 / 51.943mm Wall thickness: 1.95mm Bearing width: 19.50mm

Position: Connecting rod Quantity: 4 pairs Shaft diameter: 51.985 / 52.000mm Housing bore: 55.600 / 55.619mm Wall thickness: 1.768mm Bearing width: 19.30mm

Bore: 84.00mm Top ring: 2.50mm 2nd ring: 2.00mm 3rd ring: 2.00mm

Bore: 80.00mm Top ring: 2.00mm 2nd ring: 1.75mm 3rd ring: 2.00mm

Bore: 72.20mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 72.20mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Crankshaft: 49.985 / 50.000mm Housing: 53.000 / 53.012mm Max Wall Thickness: 1,494mm Max Length: 19,401mm Quantity: for 1 journal only
