Bore: 82.51mm Top ring: 1.20mm 2nd ring: 1.50mm 3rd ring: 2.00mm

Bore: 76.51mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 76.76mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 77.01mm Length: 50.1 mm Compression Height: 29.12 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 5.6 mm Valve Pocket Depth 1: 3.8 mm Valve Pocket Depth 2: 1.1 mm Surface: Coated Top Land Height: 5.8 mm Production Number: 76 L 92 Piston Clearance: 0.07 mm Piston rings: 1.20x1.50x2.00mm

Bore: 76.51mm Length: 50.2 mm Compression Height: 29.2 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 4.6 mm Valve Pocket Depth 1: 3.6 mm Valve Pocket Depth 2: 0.8 mm Surface: Hard Anodized Top Land Height: 5.7 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 76 L 135 Piston Clearance: 0.07 mm Piston rings: 1.20x1.20x2.00mm

Bore: 76.76mm Length: 50.2 mm Compression Height: 29.2 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 4.6 mm Valve Pocket Depth 1: 3.6 mm Valve Pocket Depth 2: 0.8 mm Surface: Hard Anodized Top Land Height: 5.7 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 76 L 135 Piston Clearance: 0.07 mm Piston rings: 1.20x1.20x2.00mm

Bore: 77.01mm Length: 50.2 mm Compression Height: 29.2 mm Pin Length: 52 mm Pin Diameter: 19 mm Recess Depth 1: 4.6 mm Valve Pocket Depth 1: 3.6 mm Valve Pocket Depth 2: 0.8 mm Surface: Hard Anodized Top Land Height: 5.7 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 76 L 135 Piston Clearance: 0.07 mm Piston rings: 1.20x1.20x2.00mm

Bore: 82.51mm Length: 50.1 mm Compression Height: 29.6 mm Pin Length: 56 mm Pin Diameter: 21 mm Recess Depth 1: 6.2 mm Valve Pocket Depth 1: 3.5 mm Surface: Coated Supplementary Article/Info 2: with piston ring carrier, without cooling duct Top Land Height: 6 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 82 L 210 Piston Clearance:...

Bore: 83.01mm Length: 50.1 mm Compression Height: 29.6 mm Pin Length: 56 mm Pin Diameter: 21 mm Recess Depth 1: 6.2 mm Valve Pocket Depth 1: 3.5 mm Surface: Coated Supplementary Article/Info 2: with piston ring carrier, without cooling duct Top Land Height: 6 mm Connecting Rod Design: Trapezoidal Connecting Rod Production Number: 82 L 210 Piston Clearance:...

Bore: 82.51mm Top ring: 1.20mm 2nd ring: 1.20mm 3rd ring: 2.00mm

Bore: 81.01mm Top ring: 1.75mm 2nd ring: 2.00mm 3rd ring: 3.00mm

Bore: 82.51mm Length: 50.6 mm Compression Height: 29.6 mm Pin Length: 59 mm Pin Diameter: 20 mm Recess Depth 1: 6.2 mm Recess Diameter: 49.25 mm Valve Pocket Depth 1: 0.76 mm Machined: with cut-out for oil jet Surface: Coated Supplementary Article/Info 2: with piston ring carrier, without cooling duct Top Land Height: 6.35 mm Connecting Rod Design:...
